TeeJet

AI6504EVS — VisiFlo Tip Celcon & 303SS Flame Red

AI6504EVS — VisiFlo Tip Celcon & 303SS Flame Red

$11.84 USD
$22.76 USD $11.84 USD
Below list
Shipping calculated at checkout.

Special order — can take up to 2–4 weeks to ship. Need it faster? Call (509) 838-2209 and we’ll check availability.
Special-order items may be non-returnable.

Not sure this is the right tip?

Enter your rate, speed and spacing and our free selector picks the TeeJet tip from what we have in stock.

Open the nozzle selector →

Questions on fitment? Need a different size or quantity?

Talk to Shayne, Brett or Jordan: real people who work on sprayers. Meet the crew
(509) 838-2209 Mon–Fri 9 AM–5 PM Pacific · Spokane, WA
Request a quote or ask about this part by email

Backorder request — tell us how many you need. We’ll confirm price and lead time before ordering; nothing is charged until you approve.

Part: SSAI6504EVS — we'll include the part number and link with your message.

🧑‍🔧
Ask Dusty Parts Expert
Get an instant answer on “AI6504EVS — VisiFlo Tip Celcon & 303SS Flame Red” — fitment, alternatives, or what else you need

AI6504EVS air induction flat spray tip, Celcon (acetal) polymer body with 303 stainless steel, Flame Red color coding. Base air-induction drift-reduction flat spray tip producing larger, air-filled droplets to reduce drift. For agricultural boom sprayer application.

Application Rates

Capacity and application rates for the AI6504EVS tip, rated 0.40 GPM at 40 PSI (pressure range shown 30–100 PSI). This size is not tabulated in TeeJet Catalog 51A, so the figures below are calculated with TeeJet’s standard formulas (GPM = rated GPM × √(PSI ÷ 40); GPA = 5,940 × GPM ÷ (MPH × spacing)), spraying water at 70°F. GPA figures are field acres on 30″ row spacing (banding over the row). Always double-check application rates by calibrating your sprayer.

PSI GPM per tip oz/min GPA at MPH
3 3.5 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5
30 0.35 45 23 19.8 17.3 15.4 13.9 12.6 11.6 10.7 9.9 9.2 8.7 8.2
40 0.40 51 26 23 19.8 17.6 15.8 14.4 13.2 12.2 11.3 10.6 9.9 9.3
50 0.45 58 30 25 22 19.8 17.8 16.2 14.8 13.7 12.7 11.9 11.1 10.5
60 0.49 63 32 28 24 22 19.4 17.6 16.2 14.9 13.9 12.9 12.1 11.4
70 0.53 68 35 30 26 23 21 19.1 17.5 16.1 15.0 14.0 13.1 12.3
80 0.57 73 38 32 28 25 23 21 18.8 17.4 16.1 15.0 14.1 13.3
90 0.60 77 40 34 30 26 24 22 19.8 18.3 17.0 15.8 14.8 14.0
100 0.63 81 42 36 31 28 25 23 21 19.2 17.8 16.6 15.6 14.7
