• TeeJet AIXR8004VK — Air Induction XR Tip Ceramic (category illustration, actual part may vary)
1 1

TeeJet

AIXR8004VK — Air Induction XR Tip Ceramic

AIXR8004VK — Air Induction XR Tip Ceramic

$9.19 USD
$17.67 USD $9.19 USD
Below list
Shipping calculated at checkout.

Special order — can take up to 2–4 weeks to ship. Need it faster? Call (509) 838-2209 and we’ll check availability.
Special-order items may be non-returnable.

Not sure this is the right tip?

Enter your rate, speed and spacing and our free selector picks the TeeJet tip from what we have in stock.

Open the nozzle selector →

Questions on fitment? Need a different size or quantity?

Talk to Shayne, Brett or Jordan: real people who work on sprayers. Meet the crew
(509) 838-2209 Mon–Fri 9 AM–5 PM Pacific · Spokane, WA
Request a quote or ask about this part by email

Backorder request — tell us how many you need. We’ll confirm price and lead time before ordering; nothing is charged until you approve.

Part: SSAIXR8004VK — we'll include the part number and link with your message.

🧑‍🔧
Ask Dusty Parts Expert
Get an instant answer on “AIXR8004VK — Air Induction XR Tip Ceramic” — fitment, alternatives, or what else you need

AIXR8004VK air induction extended range flat spray tip, 80° spray angle, 0.4 GPM at 40 PSI (red), ceramic construction. Air-induction drift-reduction tip that draws air into the spray stream to produce larger, air-filled droplets for reduced drift with systemic herbicides. For agricultural boom sprayer application.

Application Rates

Capacity and application rates for the AIXR8004VK tip, rated 0.40 GPM at 40 PSI (pressure range shown 15–90 PSI). This size is not tabulated in TeeJet Catalog 51A, so the figures below are calculated with TeeJet’s standard formulas (GPM = rated GPM × √(PSI ÷ 40); GPA = 5,940 × GPM ÷ (MPH × spacing)), spraying water at 70°F. GPA figures are for broadcast spraying on 20″ nozzle spacing. Always double-check application rates by calibrating your sprayer.

PSI GPM per tip oz/min GPA at MPH
4 5 6 8 10 12 15 20
15 0.24 31 17.8 14.3 11.9 8.9 7.1 5.9 4.8 3.6
20 0.28 36 21 16.6 13.9 10.4 8.3 6.9 5.5 4.2
30 0.35 45 26 21 17.3 13.0 10.4 8.7 6.9 5.2
40 0.40 51 30 24 19.8 14.8 11.9 9.9 7.9 5.9
50 0.45 58 33 27 22 16.7 13.4 11.1 8.9 6.7
60 0.49 63 36 29 24 18.2 14.6 12.1 9.7 7.3
75 0.55 70 41 33 27 20 16.3 13.6 10.9 8.2
90 0.60 77 45 36 30 22 17.8 14.8 11.9 8.9
