FMCSC-200F-HYD-210-CI — Pump, Hydraulic Drive, 2" x 1.5", Flanged, SC
FMCSC-200F-HYD-210-CI — Pump, Hydraulic Drive, 2" x 1.5", Flanged, SC
Questions on fitment? Need a different size or quantity?
Request a quote or ask about this part by email
FMCSC-200F-HYD-210-CI hydraulic-driven centrifugal pump, 2" x 1.5" ports, cast iron impeller, silicon carbide mechanical seal (severe duty), flanged connections. Flow rate up to 200 GPM at 80 PSI. For agricultural spraying and liquid transfer applications.
Build options on this model: cast iron impeller. Where the list shows standard and optional versions of a part, order the one that matches these options.
Service Parts
| Ref. | Part No. | Description | Qty |
|---|---|---|---|
| 1 | BAC-53 | Pipe plug | 4 |
| 1 | 41120 | Pipe plug, stainless steel (optional) | 4 |
| 2 | 7AC-14-FLG | Volute, 300 standard flange x 220 full port flange | 1 |
| 3 | BAC-23-A | Nut, 3/8" NF, cad plated | 1 |
| 3 | BAC-23-B-SS | Nut, 3/8" NF, SS (optional) | 1 |
| 4 | BAC-24-HYD-SS | Washer, 3/8" star, stainless steel | 1 |
| 4 | BAC-24-B-SS | Washer, 3/8" SS, vibration proof (optional) | 1 |
| 5 | BAC-26-200-P | Impeller, with extended keyway, thermoplastic | 1 |
| 5 | BAC-26-200-CI | Impeller, with extended keyway, cast iron (optional) | 1 |
| 5 | BAC-26-200-SS | Impeller, with extended keyway, 316 stainless steel (optional) | 1 |
| 6 | BAC-4A | O-ring, body seal | 1 |
| 7 | BAC-7SC | Seal, mechanical, silicon carbide (includes 40160 "O" Ring) | 1 |
| 7A | 40160 | O-ring, shaft seal | 1 |
| 9 | 40950 | Cap screw, 3/8" NC x 3/4" hex head | 4 |
| 9 | 40930 | Cap screw, 3/8" NC x 3/4" hex head, stainless steel (optional) | 4 |
| 10 | 41330 | Cap screw, 5/16" N.C. x 3/4" hex head, motor to pump | 4 |
| 11 | BAC-54 | Slinger | 1 |
| 12 | BAC-33 | Snap ring, internal, BAC-14 mounting frame | 2 |
| 13 | BAC-37 | Ball Bearing, sealed, BAC-6 shaft | 2 |
| 14 | BAC-32 | Snap ring, external, BAC-6 shaft | 2 |
| 15 | BAC-32-S | Spacer for BAC-6 shaft | 1 |
| 16 | BAC-25 | Key, 1/8" x 1/8" x 13/16", extended keyway | 1 |
| 17 | BAC-6-HYD-200-SS | Shaft, extended keyway, tang, stainless steel | 1 |
Hydraulic Motor
| Ref. | Part No. | Description | Qty |
|---|---|---|---|
| BAC-75-HYD-210 | Motor, 10 GPM Hydraulic | 1 |
Repair Kits
| Kit No. | Description |
|---|---|
| RK-FMCSC | Repair Kit Assembly, Silicon Carbide Seal |
| RK-BAC-75-HYD-L | Repair Kit Assembly, 200 Series Hydraulic Motor |
Ace’s sheet for this pump shows a different motor; the mounting frame, spacer, fittings and restrictor for the -210 motor can differ, so call us to confirm those parts.
This model has the silicon carbide shaft seal — use the silicon carbide seal and repair kit shown.
Parts per Ace Pump Corporation product sheet FMC-200F-HYD-304 (rev 04/13). Not sure which part you need? Send a photo of the pump tag to sales@spraycenter.com or call (509) 838-2209.
