    Ace Pumps

    FMCSC-CW-650 — Pump, 1.5"x1.25"x6.5", CW

    FMCSC-CW-650 — Pump, 1.5"x1.25"x6.5", CW

    $1,111.20 USD
    $1,852.00 USD $1,111.20 USD
    Sale
    Shipping calculated at checkout.
    Title

    Special order — allow about 2 weeks for shipping. Need it faster? Call (509) 838-2209 and we’ll check availability.
    Special-order items may be non-returnable.

    Questions on fitment? Need a different size or quantity?

    Talk to Shayne, Brett or Jordan: real people who work on sprayers. Meet the crew
    (509) 838-2209 Mon–Fri 9 AM–5 PM Pacific · Spokane, WA
    Request a quote or ask about this part by email

    Part: APFMCSC-CW-650 — we'll include the part number and link with your message.

    🧑‍🔧
    Ask Dusty Parts Expert
    Get an instant answer on “FMCSC-CW-650 — Pump, 1.5"x1.25"x6.5", CW” — fitment, alternatives, or what else you need

    FMCSC-CW-650 belt driven centrifugal pump, 1.5" x 1.25" ports, silicon carbide mechanical seal (severe duty), clockwise (CW) rotation. Flow rate up to 140 GPM at 160 PSI. For agricultural spraying and liquid transfer applications.

    Service Parts

    Ref. Part No. Description Qty
    1 BAC-53 Pipe plug, 1/8" NPT 3
    1 41120 Pipe plug, 1/8" NPT, stainless steel (optional) 3
    2 ACAL-12-650 Volute, 1-1/2" x 1-1/4" CW rotation, cast iron, e-coated 1
    3 40930 Cap screw, 3/8" NC x 3/4" hex head, stainless steel 1
    4 30029 Washer, 3/8" stainless steel, sealing 1
    5 BAC-26-650 Impeller, cast iron, e-coated 1
    5 BAC-26-650-SS Impeller, stainless steel (optional) 1
    6 BAC-4-150 "O" Ring, volute seal 1
    7 BAC-7SC-650 Seal, silicon carbide mechanical seal 1
    8 BAC-14-650-MAG Mounting frame, cast iron, e-coated 1
    9 40950 Cap screw, 3/8" NC x 3/4" Hex Head 8
    10 BAC-54-650 Slinger 1
    11 41943 Snap ring, internal, BAC-14-650 2
    12 40875 Bearing, BAC-6-650-SS driven shaft 2
    13 ACAL-32 Snap ring, external, BAC-6-650-SS 1
    14 BAC-32-650 Spacer for BAC-6-650-SS 1
    15 41085 Key, .188 x .188 x .875 1
    16 BAC-6-650-SS Shaft, 1" keyed driven, stainless steel 1
    17 BAC-50 Key, 3/16" x 3/16" x 1-1/4" 1

    Repair Kits

    Kit No. Description
    RK-FMCSC-650 Repair Kit Assembly

    This model has the silicon carbide shaft seal — use the silicon carbide seal and repair kit shown.

    Parts per Ace Pump Corporation product sheet FMC-CW-650 (sheet title: High Performance Magnetic Clutch Driven Centrifugal Pump). Not sure which part you need? Send a photo of the pump tag to sales@spraycenter.com or call (509) 838-2209.
