FMCSC-CW-800-DRB — Pump, 2" x 1.5" x 8"
FMCSC-CW-800-DRB — Pump, 2" x 1.5" x 8"
Regular price
$1,508.40 USD
Regular price
$2,514.00 USD
Sale price
$1,508.40 USD
Unit price
per
Shipping calculated at checkout.
Questions on fitment? Need a different size or quantity?
Talk to Shayne, Brett or Jordan: real people who work on sprayers. Meet the crew
(509) 838-2209
Mon–Fri 9 AM–5 PM Pacific · Spokane, WA
Request a quote or ask about this part by email
🧑🔧
Ask Dusty
Parts Expert
Get an instant answer on “FMCSC-CW-800-DRB — Pump, 2" x 1.5" x 8"” — fitment, alternatives, or what else you need
FMCSC-CW-800-DRB belt driven centrifugal pump, 2" x 1.5" ports, silicon carbide mechanical seal (severe duty), double-row bearings, large-diameter impeller, all-iron construction, clockwise (CW) rotation. Flow rate up to 180 GPM at 170 PSI. For agricultural spraying and liquid transfer applications.
Service Parts
| Ref. | Part No. | Description | Qty |
|---|---|---|---|
| 1 | ACAL-4 | "O" ring for ACAL-14 volute seal | 1 |
| 1 | 9000 | Gasket, 8 hole, obsolete Jan. 96 | 1 |
| 2 | ACAL-6-SS-A | Shaft, stainless steel | 1 |
| 3 | ACAL-14 | 2" x 1-1/2" Volute | 1 |
| 4 | ACAL-15 | Mounting frame | 1 |
| 5 | ACAL-37-DRB | Bearing, double row | 2 |
| 6 | TYPE 21-984-SC | Seal, .984" type 21, silicon carbide | 1 |
| 7 | ACAL-26-75 | 8" Impeller with keyway | 1 |
| 8 | BAC-53 | 1/8" NPT pipe plug | 3 |
| 8 | 41120 | 1/8" NPT pipe plug, stainless steel (optional) | 3 |
| 9 | GE-54 | Slinger | 1 |
| 10 | ACAL-32 | External snap ring | 2 |
| 11 | BACG-33 | Internal snap ring | 2 |
| 12 | BACG-44-A | 9/16" Lockwasher, stainless steel | 1 |
| 13 | 45195 | 9/16" - 18 Lock nut, hex | 1 |
| 15 | 73010 | "O" Ring for seal cartridge | 1 |
| 16 | 41079 | 3/16" x 3/16" x 1/2" Impeller key | 1 |
| 17 | BAC-50 | 3/16" x 3/16" x 1-1/4" Shaft key | 1 |
| 18 | ACAL-32-S-A | Spacer for ACAL-6 Shaft | 1 |
| 19 | 40950 | 3/8" NC x 3/4" hex head cap screw | 8 |
| 19 | 40930 | 3/8" NC x 3/4" cap screw, stainless steel (optional) | 8 |
| 20 | 41472 | Bullet, seal installation tool |
Repair Kits
| Kit No. | Description |
|---|---|
| RK-FMCSC-CW-800 | Repair Kit Assembly, Silicon Carbide Seal |
This model has the silicon carbide shaft seal — use the silicon carbide seal and repair kit shown.
Parts per Ace Pump Corporation product sheet FMC-CW-800. Not sure which part you need? Send a photo of the pump tag to sales@spraycenter.com or call (509) 838-2209.
