Hypro ShurFlo SF-1100 Mini-Bulk Chemical Transfer Pump, 12 VDC, EPDM
Hypro ShurFlo SF-1100 Mini-Bulk Chemical Transfer Pump, 12 VDC, EPDM
Regular price
$459.05 USD
Regular price
$811.01 USD
Sale price
$459.05 USD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Questions on fitment? Need a different size or quantity?
Talk to Shayne, Brett or Jordan: real people who work on sprayers. Meet the crew
(509) 838-2209
Mon–Fri 9 AM–5 PM Pacific · Spokane, WA
Request a quote or ask about this part by email
🧑🔧
Ask Dusty
Parts Expert
Get an instant answer on “Hypro ShurFlo SF-1100 Mini-Bulk Chemical Transfer Pump, 12 VDC, EPDM” — fitment, alternatives, or what else you need
The SF-1100 is a Hypro SF-1100 Series mini-bulk chemical transfer pump — polypropylene upper and valve housing, aluminum lower housing, Santoprene diaphragm, rated at 10.7 GPM at open flow on 12 VDC, priming up to 12 feet.
Repair Kits for This Pump
| If the pump... | Kit |
|---|---|
| Lost flow, won't hold prime, or chemical weeping at the seam | 94-719-00 diaphragm, lower housing and drive |
| Runs but won't prime or pulses | 94-720-00 valve housing (EPDM, standard) or 94-720-05 (Viton) |
| Cracked upper housing | 94-721-00 upper housing |
| Motor dead or burned out | 94-718-00 motor assembly (includes cord, clips and fuse) |
Not sure which kit you need? Send a photo of the pump label to sales@spraycenter.com or call (509) 838-2209 and we'll match it before you order.
Specifications
| Max flow | 10.7 GPM (40 l/min) at 0 PSI |
|---|---|
| Flow at 15 PSI | 7.6 GPM (29 l/min) |
| Max pressure | 15 PSI (1.0 bar) |
| Amp draw at 0 PSI | 9.3 A |
| Amp draw at 15 PSI | 13.9 A |
| Voltage | 12 VDC |
| Power cord | 20 ft cord with alligator clips and in-line fuse |
| Inlet port | 2" NPT |
| Discharge port | 1" NPT |
| Self-priming | Up to 12 ft |
| Duty | Intermittent duty |
| Max fluid temperature | 130 F (54.4 C) |
| Upper / valve housing | Polypropylene |
| Lower housing | Aluminum |
| Diaphragm | Santoprene |
| Valves | EPDM (SF-1105 is the Viton version) |
| O-ring | Viton |
| Fasteners | Stainless steel screws |
| Type | Positive-displacement diaphragm, self-priming |
Service Parts
| Ref. | Part No. | Description | Qty |
|---|---|---|---|
| 1 | 94-718-00 | Motor assembly kit | 1 |
| 2 | 94-719-00 | Diaphragm/lower housing/drive assembly kit | 1 |
| 3a | 94-720-00 | Valve housing assembly kit (EPDM) | 1 |
| 4 | 94-721-00 | Upper housing assembly kit | 1 |
Repair Kits
| Kit No. | Description |
|---|---|
| 94-720-05 | Valve housing assembly kit (Viton) - ref 3b, the SF-1105 elastomer option |
| 94-723-00 | Alligator clips / fuse kit |
| 94-724-00 | Recirculation lid kit |
| 94-725-00 | Recirculation cap kit |
Parts and specifications per Hypro manual 911-729 Rev. C (4/12).
