TeeJet
TTJ60-110025VP-CE-W-10X — Turbo TwinJet TeeJet Tip With Wilger Adapter 10PK
TTJ60-110025VP-CE-W-10X — Turbo TwinJet TeeJet Tip With Wilger Adapter 10PK
Questions on fitment? Need a different size or quantity?
Request a quote or ask about this part by email
TTJ60-110025VP-CE-W-10X Turbo TwinJet flat spray tip, 110° spray angle, 0.25 GPM at 40 PSI (lilac), polymer/acetal construction. Produces a twin spray pattern with Coarse-to-Medium droplets, giving improved coverage for contact products. Includes Wilger adapter cap assembly; sold as a 10-pack. For agricultural boom sprayer application.
Application Rates
Capacity and application rates for the TTJ60-110025 tip from TeeJet Catalog 51A (rated pressure range 20–90 PSI, 100-mesh tip strainer recommended). GPA figures are for broadcast spraying on 20″ nozzle spacing. Tabulations are based on spraying water at 70°F. Always double-check application rates by calibrating your sprayer.
| PSI | Drop size | GPM per tip | oz/min | GPA at MPH | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 4 | 5 | 6 | 8 | 10 | 12 | 15 | 20 | ||||
| 20 | VC | 0.18 | 23 | 13.4 | 10.7 | 8.9 | 6.7 | 5.3 | 4.5 | 3.6 | 2.7 |
| 30 | C | 0.22 | 28 | 16.3 | 13.1 | 10.9 | 8.2 | 6.5 | 5.4 | 4.4 | 3.3 |
| 40 | C | 0.25 | 32 | 18.6 | 14.9 | 12.4 | 9.3 | 7.4 | 6.2 | 5.0 | 3.7 |
| 50 | C | 0.28 | 36 | 21 | 16.6 | 13.9 | 10.4 | 8.3 | 6.9 | 5.5 | 4.2 |
| 60 | C | 0.31 | 40 | 23 | 18.4 | 15.3 | 11.5 | 9.2 | 7.7 | 6.1 | 4.6 |
| 70 | M | 0.33 | 42 | 25 | 19.6 | 16.3 | 12.3 | 9.8 | 8.2 | 6.5 | 4.9 |
| 80 | M | 0.35 | 45 | 26 | 21 | 17.3 | 13.0 | 10.4 | 8.7 | 6.9 | 5.2 |
| 90 | M | 0.38 | 49 | 28 | 23 | 18.8 | 14.1 | 11.3 | 9.4 | 7.5 | 5.6 |
Drop size (ASABE S572): M = Medium, C = Coarse, VC = Very Coarse.
