Hypro ShurFlo 94-238-03 Diaphragm, Lower Housing & Drive Kit for 2088 Series 3.0 GPM Pumps

Hypro ShurFlo 94-238-03 Diaphragm, Lower Housing & Drive Kit for 2088 Series 3.0 GPM Pumps

$43.06 USD
$61.04 USD $43.06 USD
Sale
Shipping calculated at checkout.
Title

Questions on fitment? Need a different size or quantity?

Talk to Shayne, Brett or Jordan: real people who work on sprayers. Meet the crew
(509) 838-2209 Mon–Fri 9 AM–5 PM Pacific · Spokane, WA
Request a quote or ask about this part by email

Backorder request — tell us how many you need. We’ll confirm price and lead time before ordering; nothing is charged until you approve.

Part: HY94-238-03 — we'll include the part number and link with your message.

🧑‍🔧
Ask Dusty Parts Expert
Get an instant answer on “Hypro ShurFlo 94-238-03 Diaphragm, Lower Housing & Drive Kit for 2088 Series 3.0 GPM Pumps” — fitment, alternatives, or what else you need

ShurFlo 94-238-03 lower housing and drive assembly kit for ShurFlo 2088 series 3.0 GPM diaphragm pumps. This is the three-chamber Santoprene diaphragm with its lower housing and drive plate, the wear parts that move the fluid. When a 2088 loses flow or pressure but the motor runs fine, or you see fluid weeping from the seam behind the pump head, the diaphragm is torn or the drive is worn, and this kit is the fix.

In stock at our Spokane, WA shop. Most 2088 rebuilds pair this with the Viton valve kit (94-232-05). If the pump also won't shut off, add the 2088 switch (94-230-36).

Kit contents

  • Diaphragm / lower housing assembly (3.0)
  • Drive assembly
  • Mounting screws

Fits

  • ShurFlo 2088 series diaphragm pumps, 3.0 (2088-343-135, 2088-394-144, 2088-443-144 and similar)

Related parts

Details

Part number 94-238-03
Manufacturer ShurFlo / Hypro (Pentair)
SKU HY94-238-03
Catalogue description L-HSG/DRIVE KIT 3.0 2088
